Характеристики
Тип прибора:
Вращающаяся голова
Тип головы:
BEAM, WASH
Угол раскрытия луча мин.:
8
Угол раскрытия луча макс.:
63
Цветовая температура:
2700, 3200, 4200, 5600, 8000
Тип цветосмешения:
RGBW, CMY
Производитель:
ROBE
Протоколы управления:
DMX-512, Art Net, RDM
Мощность головы, Вт:
555
Описание
Источник
- Light source: 37x15W RGBW multichips
- Led Life Expectancy: minimum 60.000 hours
- Typical Lumen Maintenance: 70% @ 60.000 hours
Оптическая система и эффекты
- High efficient component optics
- Linear motorized zoom 8° – 63°
- Beam and Wash zoom mode
- RGBW, 8 or 16 bit colour mixing
- CTO filter
- Virtual colour wheel with pre-programmed 237 colours including whites (2.700 K, 3.200 K, 4.200 K, 5.600 K and 8.000 K)
- Three LED rings
- Individual colour control of each LED ring
- Tungsten lamp effect at whites 2700 K and 3200 K
- Colour rainbow effects in both directions with variable speed
- Zone colour effects in both directions with variable speed
- High resolution dimmer 0–100%
- Strobe effect with variable speed (max. 20 flashes per second)
- Individual zone strobe effects with variable speed
- Pre-programmed random strobe & pulse effects
- Removable Beam shaper with motorized rotation +/- 90°
Электротехнические характеристики
- Electronic auto-ranging
- Input voltage: 100–240 V AC, 50–60 Hz
- Max. power consumption: 420 W
Габариты
- Height: 444 mm (17.5")
- Width: 300 mm (11.8")
- Depth: 203 mm (8.0")
- Weight: 11.5 kg (25.4 lbs)
Температурные характеристики
- Maximum ambient temperature: 45 °C (113 °F)
- Maximum housing temperature: 75 °C (167 °F)
Управление и программирование
- Setting & Addressing: ROBE Navigation System 2 (RNS2)
- Protocols: USITT DMX-512, RDM, ArtNet, MA Net, MA Net2
- Wireless CRMX™ technology from Lumen Radio included as optional accessory
- Pan/Tilt movement: 450°/300°
- Control channels: 38, 22, 16, 11, 38
- 5 DMX protocol modes
- 3-editable programs, each up to 100 steps
- Stand-alone operation
- Ethernet port: Art-Net protocol, ready for ACN
- Data in/out: Locking 3-pin & 5-pin XLR
- Built-in analyzer for easy fault finding
Монтаж
- Mounting points: 2 pairs of ¼-turn locks
- 2x Omega brackets with ¼-turn quick locks
